Excursion C-Zone Digital Wiring System
Load Operation:
Sequential button pushes to operate the loads.
First Push: Both Navigation Light & Anchor Light come on.
Second Push: Navigation Light shuts off, Anchor Light Stays on.
Third Push: Navigation Light and Anchor Light turn off.
Momentary push to operate the horn.
Push Button is On/Off.
Push Button is On/Off. No Timer.
Push Button is On/Off.
Turns on Bow Live well Fill Pump on a timer that follows 6 min on/3 min off cycles.
Button is On/Off
Short Press, when the System is off turns on the system. The Back Light will Turn on. All of the load buttons will flash for a few seconds before load operation will function.
Long Press is required to shut the system off. Push and Hold the Button for 4 Seconds. The load lights will flash once and back light will shut off.
Short press while the system is on will temporarily dim the back light, the system is NOT shut off in this state.
Button is On/Off
Short Press, when the System is off turns on the system. The Back Light will Turn on. All of the load buttons will flash for a few seconds before load operation will function.
Long Press is required to shut the system off. Push and Hold the Button for 4 Seconds. The load lights will flash once and back light will shut off.
Short press while the system is on will temporarily dim the back light, the system is NOT shut off in this state.
Modes offered in MFD:
Changes the timer for Live Well from 6 minutes on/3 minutes off to 3 minutes on/3 minutes off.
Does not turn on when activated just adjusts the time cycle for future Aerator operation.
When Activated, The Live well will turn on for 3 Mins to fill and automatically go into Aerate Mode.
To get out of Fish-On Mode, turn on Aerator or Press Fish-Off.
When Activated, The Live well Aerate Features will turn off.
- SIMRAD NSO evo3/3S, Display Sizes: 16, 19, and 24
- SIMRAD NSS evo3/3S, Display Sizes: 7, 9, 12, and 16
- SIMRAD GO, Display Sizes: 5, 7, 9, and 12
- B&G Zeus 3s Glass Helm, Display Sizes: 16, 19, and 24
- B&G Zeus 3s, Display Sizes: 7, 9, 12, and 16
- B&G Vulcan, Display Sizes: 5, 7, 9, and 12
- Lowrance HDS Live, Display Sizes: 7, 9, 12, and 16
- Lowrance Elite FS, Display Sizes: 7 and 9
- Garmin GPSMAP 8600, Display Sizes: 10, 12, 16, 17, 22, and 24
- Garmin GPSMAP 8400, Display Sizes: 10, 12, 16, 17, 22, and 24
- Garmin GPSMAP X2, Display Sizes: 10 and 12
- Garmin GPSMAP X3, Display Sizes: 7, 9, and 12
- Garmin Echomap Ultra, Display Sizes: 10 and 12
- Raymarine Axiom, Display Sizes: 7, 9, and 12
- Raymarine Axiom+, Display Sizes: 7, 9, and 12
- Raymarine Axiom Pro, Display Sizes: 9, 12, and 16
- Raymarine Axiom XL, Display Sizes: 16, 19, 22, and 24
- Humminbird Apex, Display Sizes: 13, 16, and 19
- Humminbird Solix, Display Sizes: 10, 12, and 15
